Power Panel Overview
1. Power Status
• No Light - Power Off
• Green - Power On
• Orange - Start-up
• Flashing Red - Power Save
2. Battery Status
• Red - 0 - 20%
• Orange - 20-70%
• Green - 70-100%
3. Charge Status
• Red - Not charging (check batteries)
• Orange - Charging in Progress
• Green - Charging almost complete
