20-18071 Rev A
Replacing Lung Bladders - 1/2
Replace the lung bladders if they leak or are damaged.
Open the torso skin as described in Opening Torso.
1. Lift the chest and chest rise plates.
2. Unhook the green lung compliance bands on each side of
the lung assembly.
3. Lift hinged lung plate.
4. Remove used lung from the socket.
5. Discard used lung.
6. Select new lung bladder.
To Next Page
