11
Link Box PLUS Connections
DC input 12V DC, 3.33 A minimum. (for power adapter**),
or 7.2V DC, 4.4A (for battery)
Ethernet RJ45 connector
Future Connector for future use
Manikin Power and signals to manikin. Pulse, sounds etc
Battery #1 Connector for Laerdal Li-Ion Battery
Blood Pressure Cuff pressure input: 0 - 300 mm Hg
USB USB A input / output
Audio in 3.5 mm jack with TRS input. Line in or microphone level
Audio out 3.5 mm jack with TRS output. Line out level
Battery #2 Connector for Laerdal Li-Ion Battery
Li-Ion Battery
Battery type Li-Ion, 4 cells
Cell type LIC 18650-22PC
Voltage 7.2 V nominal
Capacity 4.4 Ah typical (32 Wh)
Size 98 x 78 x 28.1 mm (3.86” x 3.07” x 1.11”)
Weight 270 g (0.6 Ib) approximately
Battery Charging
Charging voltage input 9 - 15V DC, 1.6 A max
Charging method Constant Current + Constant Voltage
Constant current 1.33A typ.
Expected cycle life 700 cycles for ≥ 1400mAh (cell)
Charging time: 0 - 80%: 30% per hour. 80% - 100%: 1 hour
Charging Indicator 1. The charging indicator is only active when there is a charging voltage present
2. Charging: Steady yellow light
3. Charged: Steady green light
** This product is intended to be supplied by a Listed Power Adapter or DC power source, rated
12Vdc, 3.33A minimum, Tma = 35 degree C, and the altitude of operation = 5000m. Contact
Laerdal for further assistance with purchasing the power source.
