laerdal Suction Unit - Battery Replacement Process; Servicing Information; Authorized Service and Repairs

5.6 Replace the Battery
Note: Use only batteries recommended by Laerdal or one of its authorized dealers.
4. To insert a battery, push it fully in and then to
the right to lock it.
5. Close the Battery Door.
6. After inserting the battery, place the LSU on
charge unless a fully charged battery is inserted.
There are no user serviceable parts inside the cabinet. Do not open
the cabinet. Refer servicing to a Laerdal Service Center or Laerdal
authorized LSU servicer. Contaminated suction units will not be
serviced by Laerdal Medical.
*If you are discarding the battery, dispose of safely according to local protocols.
18
6. Servicing
1. Open the Battery Door.
2. To remove the battery,
push and move it slightly to
the left and then release.
3. Withdraw the battery
from the LSU.*
