SPECIFICATIONS
GENERAL
Transmiter Crystal Controlled PLL Synthesizer
Receiver Double Conversion, Superheterodyne System
Voltage Operation 12V DC To 24V
Channel Step 10KHz
Dimension 178 (W) x 156 (D) x 48 (H) mm
Weight Approx. 1.1kg
3.5 mm external spk jack Mono Type
3.5 mm PA Jack Mono Type
Antenna connector So239 (50 Ohms socket for PL259 plugs)
TRANSMITTER
Output power FM 4 W / AM 4 W
Frequency range Please refer to page 22
Frequency tolerance +/- 200 Hz
Modulation sensitivity 2.5 mV (1250 Hz input)
Modulation capablity AM 85% / FM 2.0 KHz
RECEIVER
Sensitivity FM -120 dBm AM -118 dBm @ SINAD 12 dB
Tight squelch close up to 47 dBm
Auto squelch -120 dBm @ +/- 4 dB
S/n ratio 40 dB
Distortion 3%
Audio output power Minimum 2 W at 8 Ω
