LAGOON 380
6
ELECTRICITY
55
The different electrical devices which work on 110 V - 220 V supply
have their switches grouped together on the right hand side of the
electrical panel.
•PROTECTION
Connect the metallic covers or boxes of the electric appliances that
are installed to the protective conductor of the boat (green
conductor with yellow stripes).
The service compartment where the fuses are located is situated
behind the electrical panel. To access this area lift up the plate
above the electrical panel in order to unclip it (2 clips), then pull it
towards you to remove the plate from the end groove into which it is
fitted.
The battery charger can be used with the shore supply function.
Access to it is gained through the locker under the port aft berth.
Turn on the charger with the circuit breaker on the electrical panel.
Concerning use and maintenance of the charger refer to its
instructions.
110 V - 220 V system
Technical room
Battery charger
ELECTRICITY
