LAGOON 380
PLUMBING
66
SEWAGE TANK
Valve - Drainage to sea
(Landmark 1)
Sewage tank
(Landmark 2/3)
Capacity: 83 liter
Seawater inlet WC
(Landmark 6)
CIRCUIT BLACK WATER TANKS
1. Valve - Drainage to sea
2. Sewage tank
To starboard (optional)
3. Sewage tank
To port
4. Deck drainage
5. Vent hole
6. Seawater inlet WC
