GENERATOR - SCHEMA
• GENERAL POINTS:
A generator is a device that can produce electricity (220V or 110V)
from a mechanical energy (fuel). The generator will fed the onboard
equipment operating at 220V or 110V, moored or sailing.
• OPERATION:
- Open the valves of supply and drainage of seawater.
- Switch the generator of the battery ON.
- Switch the generator breaker (referencie 5) ON.
- Turn the generator on by remote control (located on the nautical
chart table) or your at your own generator.
- Check that any device is not running 220V or 110V. Then, change
the switch spring / generator (located at the table charts).
• OPERATION:
- Supply - Diesel:
The generator is fed by fuel through the fuel tank port. The fuel filter
(reference 1) is located at the generator circuit.
- Refrigeration:
The generator is cooled::
by seawater (inlet valve reference 8 sea water and sea water filter
reference 2) ;
and by air (air exhaust duct, thats runs through a ventilator and
through the fresh air inlet).
- Electricity:
The generator includes its own battery to start the engine. The ge-
nerator is connected to earth by a ground plane wich is located
beneath the hull.
- Rejection:
The cooling water and exhaust gases are separated in the separa-
tor (reference 7) to avoid noise pollution.
The seawater is discharged below the waterline (Landmark 9). The
exhaust- pipe is located above the waterline (Landmark 10).
Selection of the supply generator.
Lever pushed: Supply - Tank.
Lever pulled: Supply - Tank.
Concerning use and maintenance of the generator,refer to its ins-
tructions.
