LAGOON 450
8
ENGINE
85
1. Key - Filler cap
2. Deck filler - Fuel
3. Engine
4. Anti-siphonage item
5. Water trap
6. Fan
7. Outlet
8. Sea water filter
9. diesel filter
10. Accumulator tank
11. Diesel tank - 500 liter
12. Battery switch - To port
13. Port engine battery 12V 110A
14. Engine instrument panel
15. Box - Engine control
16. Starboard engine battery 12V 110A
17. Battery switch - To starboard
18. Fan
19. Engine compartment ventilator 12V
20. Sail drive
21. Propeller
A. Inlet - fresh air - Port engine - 100 mm diameter
B. Hot air extraction - Port engine - 70 mm diameter
C. Hot air extraction - Starboard engine - 70 mm diameter
D. Inlet - fresh air - Starboard engine - 100 mm diameter
E. Extinguisher access hole
ENGINE
