Operator's Manual – Lighthouse
© LAI GAMES
Page 38
LAMPS
COIN DOOR LAMPS
The coin door lamps all are 12V/DC GE194 or equivalent and can be accessed
through the coin door.
BUTTON LAMPS
The button lamps all are 12V/DC GE194 or equivalent and can be accessed
through the coin door or back door.
HEADER LAMPS
There is one standard FL 15 fluorescent tube for the Header Display. Access is by
the removing of the machine header cover and accessing the tube from the front.
PRIZE DISPLAY DOWN LAMPS
There are 2 x 12V 20W 36Dgr-halogen lamps mounted in the top of the prize
display. These are standard dichroic lamps and are accessed from the prize display
through the prize display door.
LEVEL DISPLAY LAMPS
These are 220 or 120VAC 40Watt filament lamps, in total 6 are installed with one
for each level, 1 to 5 and one for the win level. These are accessed from the rear
of the machine.
BEACON LAMP
This is a U401 BC 12V 23W halogen lamp and accessing the beacon is from the
back door.
* WARNING! *
Always turn OFF Mains power and unplugged the game, before replacing any
lamps.
Always allow time for cooling as Lamps that have been active for a time may still
be too hot to touch.
* CAUTION! *
Always replace the lamps with the same or equivalent size, wattage and voltage.
