LAI Games Lighthouse User Manual

Operator's Manual – Lighthouse
© LAI GAMES
Page 6
FITTING PRIZES TO THE PRIZE ARM
STEP ONE: Removal of Prize Locking Pin.
STEP TWO: Attachment of Hanging Ties.
STEP THREE: Loading of Prizes.
1. Unscrew the Prize Locking pin
(left-hand thread), by turning it
in a clockwise direction.
2. Remove the pin by pulling it all
the way out.
1
2
Allow a loose,
3-finger gap
in the hanging
tie.
 Attach the prizes securely to the
Hanging Ties.
* NOTE! *
Be sure to allow a loose, 3-finger gap in
the „hanging tie‟ to ensure that the
„hanging tie‟ does not interfere with the
operation of the Prize Arm mechanism.
 Load the prize arm by sliding the
Hanging Tie over the entire arm, as
shown making sure that the prizes are
facing towards the customer.
* NOTE! *
Lighthouse is shipped from the factory
with the Locking Pins in the Cashbox.
