LAI Games Speed Of Light User Manual

Operator's Manual – Speed Of Light
© LAI GAMES
Page 46
BAFB152 OUTPUT LIST
J1 ( JST 8 Way)
1. +12V
2. -
3. GND
4. -
5. Data 1
6. Data 2
7. Data 3
8. Clock
JP1. ( 4 Way JST )
1. +12V
2. +12V
3. GND
4. GND
J2. (16 Way Mini Fit Connector)
J3. ( 16 Way Mini Fit Connector )
PIN
Description
PIN
Description
1
Out Button 15
9
Out Button 22
2
Out Button 16
10
Out Button 23
3
Out Button 17
11
Out Button 24
4
Out Button 18
12
Out Button 25
5
Out Button 19
13
Out Button 26
6
Out Button 20
14
Out Button 27
7
Out Button 21
15
Out Button 28
8
+12V Out
16
+12V Out
PIN
Description
PIN
Description
1
Out Button 1
9
Out Button 8
2
Out Button 2
10
Out Button 9
3
Out Button 3
11
Out Button 10
4
Out Button 4
12
Out Button 11
5
Out Button 5
13
Out Button 12
6
Out Button 6
14
Out Button 13
7
Out Button 7
15
Out Button 14
8
+12V Out
16
+12V Out
