Operator's Manual – Speed Of Light
© LAI GAMES
Page 45
EDGE CONNECTOR PINOUT
COMPONENTS SIDE
SOLDER SIDE
GND 1
A GND
GND 2
B GND
+12VDC 3
C +12V
+12VDC 4
D +12V
P1A7 5
E P1B7 Test button
P1A6 6
F P1B6 Service button
P1A5 7
H P1B5 Start Button
P1A4 8
J P1B4 Ticket 2 Notch
Link mode button P1A3 9
K P1B3 Ticket 1 notch
Mode 3 button P1A2 10
L P1B2 Coin1
Mode 2 button P1A1 11
M P1B1 Coin2
Mode 1 button P1A0 12
N P1B0
(watch dog) P1C7 13
P P2C7 (watch dog)
P1C6 14
R P2C6 Display 7seg clock
P1C5 15
S P2C5 Display 7seg data
P1C4 16
T P2C4
Score 2 Data P1C0 17
U P2C0 RSL Board 1 Data (FB152)
Score 2 Clock P1C1 18
V P2C1 RSL Board 2 Data (FB152)
Score 1 Data P1C2 19
W P2C2 RSL Board 3 Data (FB152)
Score 1 Clock P1C3 20
X P2C3 RSL Board Clock (FB152)
GND 21
Y GND
GND 22
Z GND
JST 7
JST 5
Base Light 1 P2A0 1
1 P2B0 (PNP) Ticket 1 motor drive
Base Light 2 P2A1 2
2 P2B1 (PNP) Ticket 2 motor drive
Leader Light P2A2 3
3 P2B2 Coin1 counter
Base Light 3 P2A3 4
4 P2B3 Coin2 counter
Base Light 4 P2A4 5
5 P2B4 Ticket 1 counter
Base Light 5 P2A5 6
6 P2B5 Ticket 2 counter
Double Ticket Light P2A6 7
7 P2B6 Start Button Light
P2A7 8
8 P2B7
