47
USER GUIDE
INTERNAL COMPONENTS
13.1 Table (Ecovip series)
To open the table
Release the stop (a).
Raise the table up to the locking point.
Pull out the supports (b).
Turn over the top (c).
To close the table
To release the table support arm, lift the table slightly
and at the same time press part (d).
Lower the table. The support arm must lock into the
stop (e).
Apply the stop (a).
a
b
b
a
c
e
d
