USER GUIDE
54
  INTERNAL COMPONENTS
• On both sides, pull down the quick-action
turnbuckle (fig. 8,3) and hang it into the holding
plate.
• On each side, fold out the handle (fig. 8,2) of the
quick-action turnbuckle and turn half a turn in a
clockwise direction.
• Plug both parts of the snap lock (fig. 8,1) together,
respectively. The grey tongue (fig. 8,4) engages.
Safety net
When using the bed, the safety net must always be
hooked.
13.5 Other components
13.5.1 Snap in tilting piece (Ecovip
series)
To open the tilting piece, pull it upward until it snaps
in position. To close it, pull the catches (a) outwards,
then lower it.
Fig. 8 - Lock (elevating roof)
The safety net can be under the mattress of the
bed.
WARNING
Never leave children in the elevating roof bed
without supervision.
WARNING
a
a
