LAMAR CA-1550–CML - Displays and Controls

1. SYSTEM OVERVIEW
Figure 1-1. Controls and displays of CA-1550
CA-1550 CHARGER / ANALYZER - OPERATING MANUAL LI-4159-CML Rev A Page 2
Meter Calibration
Test points
12 volt CP Adjust 24 Volt CP Adjust
Adjustment Tool
Timer
Voltmeter
Ammeter
Battery Voltage selector
Voltage cutoff adjuster
Voltage Cutoff View
Discharge Current Adjust
Charge/Discharge selector
Pass/Fail Indicators
Charge Current Adjust
Mains On/Off/Reset
