PARTS REFERENCE
PAGE 3
L 7350
L 7350 PARTS LISTING
ITEM # PART NUMBER DESCRIPTION QTY.
1 NA MAIN BASE ASSEMBLY 1
2 23139 FRONT STABILIZER ASSEMBLY 1
3 05195 END CAPS 1
4 23135 REAR STABILIZER ASSEMBLY 1
5 05189 LEFT PEDAL 1
6 05190 RIGHT PEDAL 1
7 13117 LEFT HANDLE ASSEMBLY 1
8 13118 RIGHT HANDLE ASSEMBLY 1
9 31012 TRAY CLAMP 2
10 31011 BOTTLE TRAY 2
11 NA SEAT SLIDER ASSEMBLY 1
12 03066 SEAT PAD 1
13 13123 BACK PAD SUPPORT 1
14 03065 BACK PAD 1
15 05196 BOOT COVER 1
16 23134 MAST 1
17 10026 COMPUTER 1
18 12072 10-PIN DATA CABLE ASSEMBLY 1
19 12073 5-PIN HR CABLE ASSEMBLY 1
20 13129 SEAT SPACERS (WEDGES) 4
21 01442 HEX SCREW M8 X 1.25 X 55 LENGTH 4
22 01401 CAP SCREWS M8 X 1.25 X 15 LENGTH 14
23 01406 H
EX SCREW M8 X 1.25 X 25 LENGTH 4
24 01434 CAP SCREW M8 X 1.25 X 25 LENGTH 8
25 01414 PHILLIPS SCREW M6 X 1.0 X 35 LENGTH 4
26 01413 P
HILLIPS TRUSS SCREW M5 X .8 X 10 LENGTH 4
27 01429 F
LAT WASHER 16 X 8 X 2.0T 14
28 01431 F
LAT WASHER 25 X 8 X 2.0T 8
29 01426 CURVED WASHER 19 X 8.5 X 1.5T 4
30 01393 L
EVELER 3
Note: All assembly hardware is referenced in metric measurements. Screws / bolts are measured by diameter, thread pitch, and
length. Washers are measured by outside diameter, inside diameter, and thickness.
Conversion Reference: 25 millimeters =1.0 inch.
