LAMAR L 7350 - Assembly Stage #5; Attach Back Pad

PAGE 9
ASSEMBLY STAGE #5
Attach Back Pad
Assembly Hardware Required:
#23 Hex Head Bolts Qty. 4 #28 Flat Washer Qt
y
. 4
Assembly Description:
A) Secure the Back Pad (#14) to the Back Pad Support (#13) using 4-Cap Screws (#23) and 4-Flat Washers (#28).
♦ Assembly Stage #5 completed
ASSEMBLY INSTRUCTION
13
28
23
14
