ASSEMBLY HARDWARE REFERENCE
PAGE 2
NOTE: Most of the listed assembly hardware has been packaged separately, but some hardware items have been preinstalled in the identified
assembly parts. In these instances, simply remove and reinstall the hardware as assembly is required. Please reference the individual assembly
steps and make note of all preinstalled hardware.
HARDWARE PACK #1
HARDWARE PACK #2
#26 CARRIAGE BOLT
#26 CARRIAGE BOLT
#27 FLAT WASHER
#27 FLAT WASHER
#28 ACORN NUT
#28 ACORN NUT
#29 TRUSS HEAD BOLT
#27 FLAT WASHER
#27 FLAT WASHER
#30 TRUSS HEAD BOLT
#30 TRUSS HEAD BOLT
#27 FLAT WASHER
#32 ALLEN BOLT
#33 SPRING WASHER
#34 FLAT WASHER
SCREWDRIVER / WRENCH COMBO
ALLEN WRENCH
#16 MOUNTING CLAMP
FRONT STABILIZER
REAR STABILIZER
SEAT PAD
SEAT BACK PAD
ASSEMBLY TOOLS
HANDLEBAR ASSY.
H-HANDLEBAR
