Lambda Vega 650 - Using Options with Combination Modules (N Option)

Vega Customer Applications Manual Section 10 - Combining Modules
Rev. A3: October 2003 Page 39 of 48
Using Options with Combination Modules.
Inhibit and Power Good Option : "N" Option.
The "N" option is available on 1slot, 1.5slot and 2slot combination modules.
When the "N" option is specified for a combination module, each module will have it's own option board fitted.
The available functions when the option is fitted are :-
Module Good.
Module Inhibit.
Remote Sense (from the option board AND from the 2pin Molex fitted as standard)
LOAD
+V
-V
+V
-V
Option boards
2 pin Molex
