Page _ 5
User manual LAM2502 LAM2503
1.
3.
5.
4.
6.
2.
7.
1.
3.
5.
4.
6.
2.
7.
5.
6.
2.
7.
8.
8.
1.
3.
4.
1. Upper chimney section
2. Recirculation vent
3. Lower chimney section
4. Fan and light controls
5. Extractor body
6. Greaselters
7. Light
8. Glass Canopy
General Information & operation
0
1. 2. 3. 4. 5.
1. 2. 3. 4. 5.
1. 2. 3. 4. 5.
Extractor layout
Control panel layout
1. Extractor Power off
2. Extractor power level 1
3. Extractor power level 2
4. Extractor power level 3
5. Extractor Light on/off
