4 Appendix
TIP:
Only passive or non-reactive units may be connected to the outputs of the R 0016 relay mod-
ule. You have to avoid any supply of 230 V into the unit via terminals 82 - 92 in the event of a
fault.
TIP:
Relay module since version 4:
A testing current has to flow in both directions at the terminals 82-86, because the relay mod-
ule will cut-off every output during the self-test and the FMS is set to fault condition.
At the supply of 230V an impedance of Z<=100kΩ is required.
At the supply of 110V an impedance of Z<=22kΩ is required.
You have to connect a suitable auxiliary load (i. e. ohmic resistance or RC module). Outputs,
which the FMS does not operate (i. e. ignition valve at start without pilot burner) do not need
any auxiliary load.
Continuous control
output Apparent
ohmic resistance
0 ...10 V > 5 kΩ
0/4 ... 20 mA < 600Ω
Signal outputs
Monitor output 4 ... 20 mA signal, apparent ohmic resistance > 600 Ω
Correction inputs: 2, adjustable to 0 ... 20 or 4 ... 20 mA
channel and effect adjustable via parameters.
Digital outputs via
relay module R 16
(Contact material AgCdO, designed for 230 V AC switching voltage)
230 V supply
terminal Kl. 81
All consumers connected to the R 16 relay module are supplied via this terminal. It is to
have fuse protection provided by the customer in the form of a max. 16A delayed action
fuse.
Main gas 1
terminal 82
Contact for actuation of the gas line-side main gas valve
max. 2 A, cos φ ≥ max. 0,4
Main gas 2
terminal 83
Contact for actuation of the burner-side main gas valve
max. 2 A, cos φ ≥ max. 0,4
Oil
terminal 84
Contact for actuation of the two oil valves
max. 2 A, cos φ ≥ max. 0,4
Ignition valves
terminal 85
Contact for actuation of the ignition valve(s)
max. 2 A, cos φ ≥ 0,4
Ignition transformer
terminal 86
Contact for actuation of the ignition transformer
max. 2 A, cos φ ≥ 0,2
