Page #79 background imageLoading...
Page #79 background image
78
10 Options
10.3.2 Factory Settings of the Digital Inputs
NOTICE
Manual activation of the relay outputs:
Position 1 input always activated
Position A input switches via external contact with 24 VDC
Position 0 input always deactivated
10.3.3 Diagnosis of the Digital Inputs
4 LEDs above the switches indicate the switching state of the digital outputs.
Digital input 1 Trigger OFFSET CALIBRATION
Digital input 2 RESET FAULT
Digital input 3 SWITCHOVER to CO
e
curve FUEL 1
Digital input 4 DEACTIVATION LIMIT VALUE 1 ... 4
Digital input 5 RESET LIMIT VALUE 1 ... 4
Digital input 6 SWITCHOVER to CO
e
curve FUEL 3
Digital input 7 SWITCHOVER to CO
e
curve FUEL 4
Digital input 8 DEACTIVATION CALIBRATION
