75
10
Options
1
Digital output module
2
LSB terminal resistance 120
3
Rotary switch for setting the
tens LSB address
4
Rotary switch for setting the ones
LSB address
5
Jumper plug
6
Manual activation
T
erminal assignment:
13/14
23/24
33/34
43/44
24 VDC
CAN H/L
Relay output 1
Relay output 2
Relay output 3
Relay output 4
V
oltage supply for L
T3-F T
ermi-
nals 77-/78+
LAMTEC SYSTEM BUS for L
T3-
F T
erminals 74 H/75 L
75
