12 PHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
LANDA PHW • 9/02
PHW EXTERIOR VIEW
ALL MODELS PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 10-02025A Label, “HOT” Warning Exhaust 1
2 2-01101 Grip, Handle (Waffle), 1" 2
3 10-08018 Label, Warning Service Cord 1
4 10-020110 Label, Use Only Kerosene 1
5 2-0103 Grommet, 1/8", Rubber 4
6 6-05152 Strain Relief, Plastic (3-1100) 1
6-051595 Fitting, Strt, LQTITE
(4-2000, 4-3000, 5-3000) 1
6-05170 Strain Relief, 3/4"
(4-2000G, 4-3000A,G) 1
7 90-3003 Screw, 1/4" x 3/4", SS Tek
(optional 30-199) 4
8 95-07121014S Top Wrap, Stainless Steel 1
9 95-07121015 Wrap, Bottom, Stainless Steel 1
10 95-07121110 Handle “J” 2
11 7-10049 Adapter, Flue, 8" Stackless Top
(optional 30-199) 1
12 10-080221 Label, PHW, Control Panel 1
13 95-07121024 Control Box, Series II 1
2-01107 Weather-stripping /ft. 4
14 90-19942 Screw, 10/32" x 3/4",
Hex Wash Slot 2
15 2-01104 Trim, 1/16" Black, 750B-2 /ft. 2
16 2-01157 Cap, PHW, w/ Fuel Gauge, 14" 1
17 2-1905 Strainer, 1/4" w/ Check Valve 1
18 2-3015 Valve Control, Metering 1
19 4-02080000 Tube, 1/4" x 1/2", Clear Vinyl /ft.8
20 4-0303 Wheel & Tire Assy, 4" 4
21 6-01060 Cord, w/ GFCI Plug, 120V 20A,
36 ft. (3-1100) 1
22 6-01059 Cord, w/ GFCI 240V, 30A, 36 ft.
(4-2000A) 1
23 6-0105 Cord, Service, SEO, 12/4 /ft.
(4-2000C/N/P, 4-3000C/F/N/P) 36
6-01041 Cord, Service, SJOWA, 12/3
(3-1100K) 15
6-0109 Cord, Service, SEO 10/4 /ft.
(4-2000B/H, 4-3000B/H/M) 36
ITEM PART NO. DESCRIPTION QTY
23 6-0108 Cord, Service, SOWA, 10/3 /ft.
(4-2000K) 15
6-010690 GFCI, 240V 1PH, 40 Amp, 36',
8/3 Cord (4-2000G,4-3000A,G) 1
24 7-01471 Insulation Gasket, Stackless Top
(optional 30-199) 1
25 10-99083 Label, Warning, Hot Water 1
26 90-20041 Collar, 5/8" Bore Shaft, 3010 4
27 95-07101012 Axle, 27", PHW 2
28 95-07121010S Chassis, All Models 1
29 2-2007 Nipple, 3/8" x 3/8" NPT ST Male1
30 10-99056 Label, PHW Plat. Series 1
31 10-020PHW Label, PHW 1
32 10-2031100 Label, 3-1100 1
10-2042000 Label, 4-2000 1
10-2043000 Label, 4-3000 1
33 4-12804000 Nozzle, SAQCMEG, 0004, Red
(4-3000) 1
4-12804015 Nozzle, SAQCMEG, 1504, Yellow
(4-3000) 1
4-12804025 Nozzle, SAQCMEG, 2504, Green
(4-3000) 1
4-12804040 Nozzle, SAQCMEG, 4004, White
(4-3000) 1
4-12804500 Nozzle, SAQCMEG, 00045,
Red, (4-2000K) 1
4-12804515 Nozzle, SAQCMEG, 15045,
Yellow, (4-2000K) 1
4-12804525 Nozzle, SAQCMEG, 25045,
Green, (4-2000K) 1
4-12804540 Nipple, SAQCMEG, 40045,
White (4-2000K) 1
4-12805000 Nipple, SAQCMEG, 0005,
Red (4-2000N/P, 5-30025N) 1
4-12805015 Nozzle, SAQCMEG, 1505,
Yellow (4-2000N/P) 1
4-12805025 Nozzle, SAQCMEG, 2505,
Green (4-2000N/P) 1
4-12805040 Nozzle, SAQCMEG, 4005,
White (4-2000N/P) 1
