PHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
15
LANDA PHW • 9/02
PHW CONTROL PANEL
ALL MODELS PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 6-4000 Contactor, CH, CE15BNS3AB,
(4-2000C) 1
6-4004 Contactor, CH, CE15CNS3AB,
(4-3000C/F) 1
6-4007 Contactor, CH, CE15DNS3AB,
(4-2000B/H) 1
6-4010 Contactor, CH, CE15ENS3AB,
(4-3000B/H/M) 1
6-4018 Contactor, CH, CE15HNS3AB-09,
(4-3000A) 1
2 6-5009 Overload, CH, C316FNA3P,
7.5-11 Amps (4-2000C) 1
6-5010 Overload, CH, C316FNA3Q, 10-14
Amps (4-3000C/F) 1
6-5011 Overload, CH, C316FNA3R,
13-19 Amps (4-2000B/H) 1
6-5012 Overload, CH, C316FNA3S,
18-24 Amps (4-3000B/H/M) 1
6-5015 Overload, CH, C316FNA3C,
29-42 Amps (4-3000A) 1
3 6-020201 Switch, 3 Pos., 115V-230V
1-3PH 1
4 6-6003 Transformer, Micron,
208/277V-120V, .500 KVA
(4-3000H) 1
6-60021 Transformer, Micron, 240/480-
120/240V, .500 KVA (4-2000C,
4-3000C) 1
6-05234 Transformer, 600V-120V, 1.00 KVA
(4-3000F) 1
6-60101 Transformer, Micron, 240/480-
120V, .050 KVA/Glass
(4-2000A/B/H, 4-3000A/B/M) 1
6-60141 Transformer, Micron, 208V-120V,
.075 KVA (4-2000G) 1
5 6-02294 Fuse, ATMR, 1 Amp, 240V
(4-2000A/B/G/H,
4-3000A/B/H/M) 2
6 6-022970 Fuse, Paper, Buss, FNM-1/2,
250V (4-2000A/B/G/H,
4-3000A/B/H/M) 1
7 6-022910 Fuse, Paper, Buss, FNM 8, 250V
(4-3000C/F) 1
6-02292 Fuse, 10 amp MDL, 380V 1
ITEM PART NO. DESCRIPTION QTY
8 6-021595 Din Rail Track /inch 5
9 6-0517 Strain Relief, 3/4" 1
10 6-051597 Bushing, Terminal 1
11 6-0515 Connector, Flex, 90°, 3/8" 1
12 6-0122 Conduit, Flex, Alum, 3/8" /ft. 2
6-01220 ▲ Conduit, Bushing, Anti-Short 2
13 6-05152 Strain, Plastic (2-1100, 3-1100) 1
6-051595 Fitting, Strt, LQ Tite
(4-2000, 4-3000) 1
6-05170 Strain Relief, 1"
(4-2000G, 4-3000A/G) 1
6-05172 ▲ Lock Nut 1
14 2-01411 Bushing, 1" Snap 1
15 2-3015 Valve, Metering 1
16 2-1085 Hose Barb, 1/4" Barb x
1/4" ML Pipe 2
17 2-9000 Clamp, Screw #4 2
18 2-0103 Grommet, 1/8", Rubber 1
19 2-01168 Cap, Rubber, Capacitor 3
20 90-017 Nut, 10/32", Keps 3
21 2-0100193 Clamp, 2" Click 3
22 90-1999 Screw, 10/32" x 3/4" BH SOC 3
23 Start Capacitor (4-3000A) 2
24 Run Capacitor (4-3000A) 1
10-02032 ▲ Label, Discharge Capacitors
(4-3000A) 1
25 90-1040 Screw, 10/32" x 1/2" Sckt, CAP 4
26 6-03565 Fuse Block (4-3000C/F/N) 1
27 6-02306 Fuses, 3 Amp, 600V
(4-2000, 4-3000C/F) 2
6-023090 Paper Fuse, FNM5 (4-2000C) 2
28 90-16 Screw, 8/32" x 3/4" (4-2000,
4-3000C/F) 1
90-200490 Nut, 8/32" Keps (4-2000,
4-3000C/F) 1
29 90-19942 Screw, 10/32" x 3/4", Hex
Wash Slot 2
30 90-2018 Nut, Cage, 10/32" x 16 Ga. 2
31 10-08021 Label, Disconnect Power Supply 1
32 4-02090000 Hose, 1/4" x 1/2", Braided Vinyl 3
33 11-1042 Label, Ground 1
