Landa PHW4-2000 - Tank Assembly Parts List; Tank Assembly Component Part Numbers

PHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
17
LANDA PHW • 9/02
PHW TANK ASSEMBLY
ALL MODELS PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 10-99083 Label, Warning Hot Water 1
2 Burner Assembly, See Burner Spec's Page 26
3 2-0039 Cross, 1/2" Female, Steel 3
4 2-00602 Elbow, 1/2" JIC x 1/2" Fem. 1
5 2-00091 Nipple, Galv., 1/2" x 3", Sch. 80 1
6 95-07121113 Insulation Retainer 2
7 7-0144 Gasket, Burner Plate 2
8 4-02047725 Hose, Pres. Loop, 100R2,
25" x 3/8" 1
9 2-00101 Nipple, Galv., 1/2" x 4", Sch. 80 1
10 2-00120 Nipple, Galv., 1/2" x 5", Sch. 80 1
11 2-00241 Coupling, 1/2" x 3/8" 1
12 2-2007 Nipple, 3/8" x 3/8" NPT ST Male1
13 7-0140 Insulation, Front Head, No Hole 1
14 2-3408 Rupture Disk Assy, 8000 PSI
(All models) 1
15 4-05091 Switch, Snap, 275 Dr Hi-Limit 1
16 95-07121015 Bottom Wrap, Stainless Steel 1
17 95-07121212 Coil Replacement, Schedule 80
w/ Steel Wrap 1
18 7-01430 Insulation, Blanket w/ No Foil
24" x 57" 1
19 7-0141 Insulation, Burner Head,
w/ Hole 1
20 7-12484 Gasket Standard - Large 2
21 95-07121014S Top Wrap, Stainless Steel 1
22 2-01104 Trim, 1/16" Black, 750B-2 /ft.3.25
ITEM PART NO. DESCRIPTION QTY
23 7-01484 Insulation, Blanket - Die Cut, 28"1
24 90-20040 Nut, 3/8" Flange Whiz Loc 2
25 90-1019 Bolt, 3/8" x 1-3/4" 2
26 90-4002 Washer, Flat, SAE, 3/8" 5
27 90-2002 Nut, ESNA, NC, 3/8" 3
28 2-1022 Elbow, Street, 1/4" 1
29 2-1002 Nipple, Close, 1/4" 1
30 2-9905 Filter, Fuel Oil/H
2
O Separator 1
2-99051 Element, Fuel/H
2
O Separator 1
31 2-1089 Hose Barb, 90°, 1/4" Barb x
1/4" Pipe 1
32 2-9000 ▲ Clamp, Screw #4 4
33 4-02100000 Hose, 1/4", Push-on, Fuel Line 2
34 2-3480 Rupture Disk Replacement,
8000 PSI (All Models) 1
35 2-90041 Screw Clamp, #16 1
36 2-1085 Hose Barb 1/4" Barb x 1/4"
ML Pipe 1
37 4-02130050 Hose, 7/8" Push On /ft. 2
38 6-0516 Strain Relief, 1/2" 1
▲ Not Shown
