PHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
19
LANDA PHW • 9/02
PHW CHASSIS
ALL MODELS PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 95-07121017 Panel, Rear Access 1
10-02028 ▲ Label, Warning -
Exposed Pulleys 1
2 90-50031 Knob, Black 3 Pt, 5/16"-18 x 1" 2
90-2023 ▲ Nut, Cage, 5/16"-18, Black 2
3 90-4001 Washer, 5/16", Flat SAE 2
4 90-1995 Screw, 1/4" x 1/2", BH SOC CS 4
5 90-2000 Nut, 1/4", ESNA, NC 2
6 95-07121010S Chassis, All 1
7 2-01101 Grip, Handle (Waffle), 1" 2
8 95-07121110 Handle, “J”, PHW 2
9 2-01157 Cap, PHW w/ Fuel Gauge, 14" 1
10 2-010063 Dip Tube, Plastic, 12" 1
11 2-01164 Tank, Float, Universal Plastic 1
12 95-07121207 Lid & Hinges, Plastic Float Tank 1
13 10-99079 Label, Stripe 1
14 95-07101012 Axle, 27", PHW 2
15 4-02100013 Inlet Hose, Supply Water, 13"
(4-2000, 4-3000) 1
16 4-02100009 Inlet Hose, Supply Water, 11"
(All Models) 1
17 4-0303 Wheel & Tire Assembly, 4" 4
18 90-20041 Collar, 5/8" Bore Shaft 3010 4
19 2-1053 Nipple, 1/2" JIC x 1/2" Pipe
(All Models) 1
20 95-07162007 Hose Connection Bracket 1
21 2-10942 Swivel, 1/2" MP x 3/4" GHF 1
22 2-1902 Strainer, Inlet Garden Hose 1
ITEM PART NO. DESCRIPTION QTY
23 90-1999 Screw, 10/32" x 3/4",
BH SOC CS 6
24 90-40002 Washer, 1/4", SAE, Black Zinc 4
25 90-2018 Nut, Cage, 10/32" x 16 Ga. 6
26 90-20231 Nut, Cage, 1/4" x 12 Ga. 2
27 2-1042 Tee, 1/2" Street
(4-2000, 4-3000) 1
28 2-1062 Elbow, 1/2" JIC x 1/2", 90°
(4-2000, 4-3000) 1
29 10-020110 Label, Use Only Kerosene 1
30 2-010066 Elbow, Fuel, Tank 1
31 90-5016 Nut, 3/8" - 16 NC Kimdorf
w/ Spring 2
32 90-4002 Washer, 3/8", SAE, Flat 2
33 90-1018 Bolt, 3/8" x 1-1/2", NC 2
34 90-10201 Bolt, 3/8" x 2-1/4" 6
35 90-2019 Nut, Cage, 3/8" x 16 GA 2
36 90-2002 Nut, 3/8" ESNA 4
37 95-07290086 Assy, Lever, Brake 1
38 90-1992 Bolt, 3/8" x 3/8" Sckt Shdr 1
39 90-2001 Nut, 5/16" ESNA 1
40 90-4002 Washer, 3/8" Flat 9
41 2-01212 Cap, Vinyl Flat, Yellow 1
42 2-1085 Hosebarb, 1/4" Barb x 1/4" ML
Pipe 1
43 2-9000 Clamp, Screw #4 4
44 4-02100000 Hose, 1/4" Push-on, Fuel Line 2
45 2-010061 Bushing, Mount, Rubber 2
▲ Not Shown
