Landa PHW4-2000 - Pump Assemblies Parts List; Pump Assemblies Component Part Numbers

PHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
21
LANDA PHW • 9/02
PHW PUMP ASSEMBLIES
PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 95-07121112 Rail, Pump Combo 1
90-2020 ▲ Nut, Cage, 3/8" x 12 GA 2
2 1-96710600 Washer 4
3 1-99364400 Screw 4
4 5-2302 Pump, General, T-991
(3-1100) 1
5-2271 Pump, AR, XRA45G30 HN
4-3000N) 1
5-2273 Pump, AR, XMA35G25N
(3-1100K, 4-2000K/N/P) 1
5-2304 Pump, General, T-1011
(4-2000) 1
5-2307 Pump, General, TS-2021
(4-3000) 1
5 4-02110000 Hose, 1/2" Push-On /ft. 3
6 2-1105 Swivel, 1/2" JIC Fem., Push-On 3
7 2-0079 Swivel, 1/2" JIC Fem., 3/8" Male1
8 2-0053 Elbow, 1/2" JIC x 3/8", 90° 1
9 2-30082 Pump Protector, 1/2" PTP 1
ITEM PART NO. DESCRIPTION QTY
10 6-02174 Replacement, Reed 1
11 4-02047725 Hose, 25" x 3/8", 100R2
Pres Loop 1
12 2-1062 Elbow, 1/2" JIC x 1/2", 90° 2
13 2-10421 Tee, 1/2" w/ 1/8" Hose, Street 1
14 2-1084 Hose Barb, 1/4" Barb x
1/8" ML Pipe 1
15 2-9000 Clamp, Screw, #4 1
16 2-00270 Elbow, 3/8" Male 1
17 2-1052 Nipple, 1/2" JIC x 3/8", 90° 1
18 2-1042 Tee, 1/2" Street
(2-1100, 3-1100) 1
19 2-0051 Nipple, 1/2" JIC, 3/8" Male 1
20 5-3208 Unloader, AL607 1
21 6-021730 Switch, Flow MV60 (Yellow) 1
▲ Not Shown
