PHW SERIES PRESSURE WASHER OPERATOR’S MANUAL
23
LANDA PHW • 9/02
PHW POWER PLATFORM
ALL MODELS PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 90-10220 Bolt, 3/8" x 3-1/2", Tap (3-1100) 2
2 90-1025 Bolt, 3/8" x 5-1/2", NC HH Tap
(4-2000, 4-30000) 2
3 90-1016 Bolt, 3/8" x 1", NC HH
(3-1100 - QTY 6;
4-2000, 4-3000 - QTY 10)
4 90-1007 Bolt, 5/16" x 1", NC HH
(3-1100) 4
5 90-4002 Washer, 5/16" SAE, Flat
(3-1100 - QTY 12;
4-2000, 4-3000 - QTY 20)
6 90-4001 Washer, 5/16", SAE, Flat
(3-1100) 8
7 90-2007 Nut, 3/8", Hex, NC 2
8 90-2002 Nut, 3/8", ESNA, NC
(3-1100 - QTY 6;
4-2000, 4-3000 - QTY 10)
9 90-2001 Nut, 5/16", ESNA, NC (3-1100) 4
10 95-07141110 Retainer, Pump Take Up
(2-1100, 3-1100) 1
11 95-07101012 Axle, 27" PHW 2
12 95-07121013 Platform, Motor (3-1100) 1
13 95-071210136 Platform, Motor, 3/16"
(4-2000, 4-3000) 1
14 95-07121010S Chassis, All 1
15 5-512024 Bushing, H x 24 mm, All 1
16 5-511113 Bushing, H x 1-1/8" (4-2000) 1
5-511075 Bushing, H x 3/4" (4-2000K/N/P)1
5-511063 Bushing, H x 5/8" (3-1100K) 1
17 5-511138 Bushing, H x 1-3/8" (4-3000) 1
18 5-40507001 Pulley, 2 BK 70 H (4-2000K) 1
5-40505501 Pulley, 2 BK 55 H (5-3000N) 1
5-40208401 Pulley, 2AK 84 H (4-2000G/P) 1
5-40508001 Pulley, 2BK 80 H (4-3000G/P) 1
5-40107401 Pulley, AK 74 H, (3-1100) 1
5-40506001 Pulley, 2 BK 60 H (4-30025N) 1
5-40407001 Pulley, BK 70 H (4-20025K/N/P) 1
5-40206401 Pulley, 2 AK 64 H (4-3000M/P) 1
19 5-40205701 Pulley, 2 AK 54H (4-3000M,P,
4-2000GP) 1
5-40403601 Pulley, BK 36 H (4-2000N/P) 1
5-40404001 Pulley, BK 40 H (4-2000K) 1
5-40505701 Pulley, 2 BK 57 H (4-3000N) 1
ITEM PART NO. DESCRIPTION QTY
19 5-40504501 Pulley, 2BK 45 H (4-3000) 1
5-40204601 Pulley, 2AK 46 H (4-20025N) 1
20 5-602035 Belt, AX35 (3-1100K, 4-3000M) 2
5-602036 Belt, AX36 (4-2000N, 4-3000P) 2
5-602037 Belt, AX37 (4-2000G/P) 2
5-603032 Belt, B-32 (4-2000N/P) 2
5-604034 Belt, BX34 (4-3000N, 4-2000K) 2
5-604036 Belt, BX36 (4-3000) 2
21 5-1011 Motor, 5 HP, 3 PH,
1725 RPM (4-2000B/C) 1
5-1013 Motor, 7.5 HP, 1 PH,
1725 RPM (4-3000A) 1
5-10145 Motor, 7.5 HP, 3 PH, 1725 RPM
(4-3000B/C) 1
5-10146 Motor, 7.5 HP, 3 PH, 1725 RPM
(4-3000F) 1
5-10401 Motor, 6 HP, 1 PH, 1725 RPM
(4-2000A) 1
5-1047 Motor, 2 HP, 1 PH, 3450 RPM
Baldor (3-1100) 1
5-1059 Motor, 5 HP 220V 1 PH,
2850 RPM, 50 Hz (4-2000K) 1
5-1061 Motor, 5 HP 3 PH, 2850 RPM,
50 Hz (4-2000N/P) 1
5-1063 Motor, 7.5 HP 3 PH,
220/380/440V, 1425 RPM
50 Hz (4-3000M) 1
5-10402 Motor, 6 HP 1 PH, 1800 RPM,
200V (4-2000G) 1
5-10111 Motor, 6 HP 3 PH, 1800 RPM
200V (4-2000H) 1
5-10131 Motor, 7.5 HP 1 PH, 1800 RPM
200V (4-3000G) 1
5-10144 Motor, 7.5 HP 3 PH, 1800 RPM
200V (4-3000H) 1
6-0516 Strain Relief, 1/2" 1
6-0517 Strain Relief, 3/4" 1
6-05171 Strain Relief, 3/4" 1
22 6-0102 Cord, 8/3 (4-2G,4-3A,4-3G) 4.25ft
