OVERVIEW OF THE ASSEMBLED GRILL
These are the main components of the Pellet Kettle.
The Pellet Kettle uses an electrically powered auger and fan that is connected to a control
panel to control the burning of fuel pellets for temperature and smoke.
Hopper lid
Open the hopper lid and add pellet fuel to the grill
as needed. Keep the hopper lid closed at all times.
Do not expose the pellets to any type of moisture
or liquid.
Grill lid
This grill is designed to operate with the lid closed
during use. The lid hinge has a built-in stop lock
that keeps the lid open. To release, lift up
on the handle to release.
Hopper Lid
Control Panel
Grill Lid
Firebowl
Grease
Bucket
Hopper
Chimney
Side Shelf
Bottom Shelf
Pellet Kettle
PROBE
TEMP
FEED
BYPASS
PROBE
POWER
150 ºC
135 ºC
120 ºC
105 ºC
SMOKE
HIGH
230 ºC
205 ºC
190 ºC
175 ºC
STANDBY
