Concept
CRManual
FEATURESCR300/400
GRAPHICEQ:
REVERBTOMAIN:
REVERBTOMON:
MASTERMONITOR:Controls
MASTERVOLUME:
FXSEND:
FXTOMAIN:
FXTOMONITOR:
PHANTOMPOWER:
POWER:
FXSEND:
FXRETURN:
REVERBFOOTSWITCH:
MONITOROUT:
LINEOUT:
A9bandgraphicequaliser
allowstheusertocompensateforhouse
acoustics.
Adjuststheoveralllevel
ofreverbtothemainoutputs.
Adjuststhelevelofreverb
senttothemonitorout.
theoutput
levelofthesignalsenttothemonitorout.
Controlstheoverall
listeningvolumeoftheamplifier.
Controlsthelevelofsignalsentto
externalprocessingequipmentconnectedvia
theFXsendandreturnsockets.
ControlsthelevelofFXreturn
signalsenttothemasteroutputs.
ControlsthelevelofFX
returnsenttothemonitoroutput.
48Vphantompoweris
providedforcondensermicrophones.Itis
globallyswitchedtoallMICXLRsocketsviaa
switchonthebackpanel.Phantompower
sourcemustalwaysbeswitchedOFFwhen
usingunbalancedsourcesconnectedtothe
MICinputsotherwisethesourcemaybe
damaged.Condensermicrophonesshouldbe
connectedtoMICinputsbeforethephantom
powerisswitchedon.
LEDindicatingthattheunitis
poweredup.
Jacksocketprovidedfor
connectingexternalprocessingdevices.Level
ofsignalpresentatthissocketcontrolledby19
forindividualchannelleveland39fortheover
allmasterlevel.
Jacksocketprovidedtoaccept
thereturnsignalfromexternalprocessors.
Allowsconnection
ofanFS1forremoteswitchingofreverb.
Sendsmixedmonitorsignal
toexternalpoweramplifieroradditional
poweredmonitor
Sendsmastersignaltoexternal
poweramplifiersoradditionalpowered
39
40
36
35
38
42
41
44 47
48
37
45
46
41
34
42
43
44
