Concept
CRManual
FEATURESCR300/400
RETURN
SPEAKEROUTPUTS:
48VPHANTOMPOWERSWITCH:
POWERSWITCH:
SPEAKONCONNECTORS:
INSERTLOOP:
Jacksocketoutputsforexternalspeakerenclosures.Total
impedanceshouldnotexceed2Ohms.
Allowstheunits48VPhantompowertobeactivated.
PowerON/OFFswitch.
Speakonconnectorsforconnectingspeakonequiped
enclosures.Undernocircumstancesshouldthetotalloadontheamplifierbelessthan
twoohms.
Anonsertloopisprovidedbeforetheinternalpoweramplifier.These
areprovidedforconnectionofproductssuchascompressors,limitersandfeedback
eliminatorsetc.Onejacksocketisprovidedforasendandonejackisprovidedfora
return.
