GUITAR INPUT: Socket provided for connecting electric guitar...
BASS: Sets the level of bass frequencies in the clean channel.
MIDDLE: Sets the level of mid frequencies in the clean channel.
TREBLE: Sets the level of high frequencies in the clean channel.
CRUNCH FACTOR ON!: Engages the CRUNCH channel
MAX BUTTON: Engages the MAX feature. This provides a scooped EQ boost to the
signal giving the amplifier a very unique distortion tone......try it out!
NOISE GATE: .The noise gate only comes into operation once you stop playing. When
the signal level to the amp reduces in sufficient volume to activate the gate, the gate shuts
down and eliminated all extraneous noise producing and absolutely silent amplifier.
LEAD BOOST SWITCH: Engages the onboard footswitchable boost facility.
LEAD BOOST LEVEL: Sets the level of the onboard footswitchable boost facility.
LEAD BOOST SOCKET: Socket for connecting FS1 footswitch enabling you to
footswitch the lead boost feature.
SPEAKER SOCKETS: Sockets for connecting external speaker cabinets. The total
impedance should not be below 4 Ohms.
CLEAN VOLUME: Sets the overall listening level of the clean channel.
CRUNCH FACTOR: Sets the level of distortion.within the crunch channel..
MASTER VOLUME: Controls the overall listening level of the overdrive channel.
BASS: Controls the low frequency EQ in the preamplifier.
MIDDLE: Controls the mid frequency EQ in the preamplifier.
TREBLE: Controls the high frequency EQ in the preamplifier.
REVERB: Sets the required level of reverb.
FOOTSWITCH: Socket for connecting FS2 footswitch enabling the footswitching of
channel and reverb features.
