1
2
10
PASSIVE INPUT: Socket provided for connecting a bass guitar equipped with passive
pickups.
ACTIVE INPUT: Socket provided for connecting a bass guitar equipped with active pickups.
COMPRESSOR GAIN: Sets the level of compression of the input signal. Should be used to
give a punchy bass sound as desired.
COMPRESSOR SWITCH: Activates the on board compressor.
BRIGHT SWITCH: Adds top end sparkle and creates a bright punchy bass response.
BASS: Sets the level of bass frequencies present in the signal..
6 BAND GRAPHIC MID: Allows greater tonal shaping of the mid frequencies to get the
desired bass sound.
TREBLE: Sets the level of high frequencies present in the signal
VOLUME: Sets the overall listening volume of the amplifier.
DI: Socket provided for connecting the amplifier to an external amplifier such as front of
house PA or providing a direct input into a recording device.
SPEAKER SOCKET: Socket for connecting external speaker. The external cabinet
cabinet should be no lower than 8 Ohms.
EFFECTS LOOP RETURN: Socket for connecting the return signal from an external effects
processor.
EFFECTS LOOP SEND: Socket for connecting to the input socket of external effects
processor.
3
11
9
12
5
6
8
4
7
1
2
10
3
11
9
13
5
6
8
4
7
Laney
1212
7
In the interest of continuing product development BLT Industries reserves the right to change specification without prior notice.
BLT Industries LTD.,
Newlyn Road
Cradley Heath
West Midlands
B64 6BE
Tel: (00 44) (0)1384 633821
Fax: (00 44) (0)1384 639186
Web Site http:/www.laney.co.uk
HCM120B
