Laney Hardcore Max HCM30 User Manual

Laney
1
2
HCM120B
3
1
4
9
10
11
2
5
6
7
8
13
10
PASSIVE INPUT: Socket provided for connecting a bass guitar equipped with passive
pickups.
ACTIVE INPUT: Socket provided for connecting a bass guitar equipped with active pickups.
COMPRESSOR GAIN: Sets the level of compression of the input signal. Should be used to
give a punchy bass sound as desired.
COMPRESSOR SWITCH: Activates the on board compressor.
BASS: Sets the level of bass frequencies present in the signal..
SWEPT MID SWEEP: Sets the frequency at which the swept mid gain control is applied.
SWEPT MID GAIN: Sets the amount of gain applied to the frequency selected by control 6.
TREBLE: Sets the level of high frequencies present in the signal
VOLUME: Sets the overall listening volume of the amplifier.
CD/LINE INPUT: Sockets for connection of external CD player.
DI: Socket provided for connecting the amplifier to an external amplifier such as front of
house PA or providing a direct input into a recording device.
HEAD PHONES: Socket for connecting external headphones. Connecting headphones
automatically isolates the internal speaker.
