GUITAR INPUT:
BASS:
MIDDLE:
TREBLE:
CRUNCH FACTOR ON!:
MAX BUTTON:
EFFECTS LEVEL:
DIGITAL X FACTOR EFFECTS:
CD/LINE INPUT:
FOOTSWITCH:
Socket provided for connecting electric guitar.
Controls the low frequency EQ in the preamplifier for the clean channel.
Controls the mid frequency EQ in the preamplifier for the clean channel.
Controls the high frequency EQ in the preamplifier for the clean channel.
Engages the CRUNCH channel
Engages the MAX feature. This provides a scooped EQ boost to the
signal giving the amplifier a very unique distortion tone......try it out!
distorted signal.
distorted signal.
Sets the overall level of the effect selected. The level control should
be used to get the desired blend between the “DRY” signal - no effect and the “WET”
signal - with effects..
Selects one of the fifteen onboard effects. See the
effects description in the MXD15 section .
Sockets for connection of external CD player.
Socket for connection of FS2 footswitch allowing remote switching of
X-Factor effects and channel status.
CLEAN VOLUME:
CRUNCH FACTOR:
MASTER VOLUME:
BASS:
MIDDLE:
TREBLE:
Sets the overall listening level of the clean channel.
Sets the level of distortion within the crunch channel..
Controls the overall listening level of the overdrive channel.
Controls the low frequency EQ in the distorted signal.
Controls the mid frequency EQ in the
Controls the high frequency EQ in the
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
