Introduction
Chapter 1
Network Application Platforms
Chapter 1:
Introduction
Thank you for choosing the FW-7541. The FW-7541 is
a desktop network communication appliance which is
built on Intel® Pineview™ embedded processor, the next-
generation in the Intel ® Atom™ family.
The FW-7541 is an ideal network system platform. All
electronics are protected in a compact sealed rugged case
for easy installation in customers’ computer facilities, or it
can be used as a stand-alone application situated in your
lab or offices where space is limited and the environment
is harsh.
The FW-7541 can be used as a standalone system, rack
mounted or desktop mounted. The system comes in a
footprint of only 174mmx140mm (6.85” x 5.51”).
The rugged aluminum case not only provides great
protection from EMI, EDS, shock/vibration, cold and heat,
but also passive cooling for quiet fanless operation (Models
C and D are fanless; models A and B are with fans)
The six Gigabit LAN ports with hardware bypass (1 pair)
capability and Mini-PCIe slot coupled with SIM card
connector answer the demand for versatility in networking
applications. It also supports a 2.5” SATA HDD and
CompactFlash for storage. All of the above mentioned are
packed into a small rugged unit (268mmx40mmx145mm)
(10.55”x1.57”x5.71”).
Please refer to the chart below for a summary of the
system’s specifications.
System Specification
FEAT URE DESCRIPTION
Form Factor Desktop
Platform
Processor
Onboard Dual-Core Intel®
ATOM D525
1.8 GHz
Chipset
Intel ICH8M
System Memory Technology DDR3 667/800 MHz, non-ECC
Max Capacity 4GB
Socket 1x204P SO-DIMM
OS Support
Windows (2000, 2003, XP)
Linux Kernel 2.4 and up
Storage
HDD Bay(s) 1 x 2.5”
Storage Interface 1 x Serial ATA, 1 x CompactFlash
Networking
Ethernet Ports 6 x GbE ports
Controller
1 x Intel 82574L LAN Chip
5 x Intel 82583V LAN Chip
By-Pass
1 pair optional
I/O Interface
Console 1 x RJ45
USB 2.0 2 x USB 2.0
Expansion
Mini-PCIe 1
Cooling
Processor Passive Heatsink
System Passive Heatsink
Environmental
Parameters
Temperature, ambient
operating / storage
0ºC ~40ºC / -20ºC~70ºC
Humidity (RH), ambient op-
erating and non-operating
5 ~ 95%, non condensing
Miscellaneous
Watchdog Yes
Internal RTC with Li Battery Yes
Physical
Dimensions
Dimensions (WxHxD)
268x 40 x 145mm
Weight 1.2KG
Power
Type / Watts 60W Adapter
System Input 12V DC
Approvals &
Compliance
CE Emission, FCC Class A, RoHS
Ordering Info
Please note that Fanless models (models C/D) only support
industrial HDD
