Lanner NCA-1516 - System Specifications; General System and Platform Details; Hardware Interfaces and Expansion; System Operational Parameters

NCA-1516 User Manual
11
Form Factor
Desktop
Platform
Processor Options
Intel® Atom® C3000
CPU Socket
1 x Onboard
Chipset
SoC
Security Acceleration
Intel® QuickAssist Technology
BIOS
AMI SPI Flash BIOS
System Memory
Technology
DDR4 1866/2133/2400MHz ECC/Non-
ECC (By SKU)
Max. Capacity
64GB
Socket
2 x 260-pin SODIMM
Networking
Ethernet Ports (By SKU)
4 x GbE RJ45 Intel® i350
2 x GbE RJ45 Intel® SoC Integrated MAC
(Optional PoE+ Support)
2 x SFP+ SoC Integrated MAC
Bypass
N/A
NIC Module Slot
N/A
LOM
IO Interface
OPMA slot
N/A
I/O Interface
Reset Button
1
LED
Power/Status/Storage
Power Button
1 x ATX Power Switch
Console
1 x RJ45
USB
2 x USB 3.0
LCD Module
N/A
Display
N/A
Power input
2 x DC Jack (Optional 2nd DC Jack)
Storage
HDD/SSD Support
N/A
Onboard Slots
1 x Onboard EMMC 8G (By Request)
Expansion
M.2
1x M.2 3052/3580 B Key (PCIe/USB 3.0)
1x M.2 3042 B Key (USB 3.0)
1x M.2 2242 B Key (SATA)
mini-PCIe
1 x Mini-PCIe (PCIe/USB2.0)
SIM card Slot
2 x Nano SIM
Miscellaneous
Watchdog
Yes
Internal RTC with Li Battery
Yes
TPM
Yes
Cooling
System
1 x Cooling Fan with Smart Fan or Fanless (By Request)
Processor
Passive CPU Heatsink
Environmental Parameters
Temperature
0~40ºC Operating
-20~70ºC Non-Operating
Humidity (RH)
5~90% Operating
5~95% Non-Operating
System Dimensions
(WxDxH)
231 x 200x 44 mm
Weight
1.2 kg
Package Dimensions
(WxDxH)
Weight
358 x 135 x 290 mm
2.75 kg
Power
Type/Watts
60W 5A/12V PSU
Input
AC 100~240V @50~60 Hz
Approvals and Compliance
RoHS, CE/FCC Class B, UL
