Lanner NCA-1516 - Rear Panel Overview; Power and Reset Controls; Connectivity Ports; Antenna and Expansion Ports

NCA-1516 User Manual
13
No.
Description
F1
Power Switch
Press to power on/off the system
F2
Reset Button
Press to perform a Hardware reset
F3
DC Jack
Power supply
F4
Console Port
1x RJ45 console port
F5
USB Port
2 x USB 3.0 port
F6
SFP Port
2 x SFP port
F7
LAN Port
6 x RJ45 port
F8
Antenna Port
4x SMA connector for the Wi-Fi / LTE module
F9
PoE Expansion
Expansion PoE Kit Port (Optional)
F1
F5
F4
F6
F7
F2
F8
F3
LTE / WiFi
F9
