Lanzar VIBE E540P - E750 s System Diagram

owner’s manual
17
system diagram
4-Speaker and subwoofer system application using the E750s
Head unit (Stereo, CD Player, Tape Deck, etc.)
Lanzar Vibe E750s Equalizer & Crossover
REAR CHANNEL
Power Amplifier
FRONT CHANNEL
Power Amplifier
to Ground (Black)
to Remote On
(Orange)
to +12v Battery
(Red)
Left and Right
Line Inputs
Rear Panel
Left and Right
Line Outputs
from Head Unit
REAR CHANNEL
Speakers
FRONT CHANNEL
Speakers
Fuse: 1A
+12 Rem Gnd
INPUT
LR
SUB
LR
REAR
LR
OUTPUT
FRONT
LR
SUB CHANNEL
Speakers
SUB CHANNEL
Power Amplifier
E750
s
LEFT output level RIGHT output level
60Hz
–
+
150Hz
–+
400Hz
–+
1kHz
–+
2.4kHz
–+
6kHz
–+
15kHz
–+
0 +10dB
front
rear
fader
40 400
–+
Subwoofer
equalizer with
subwoofer crossover
–+
–+
–+
–+
–+
–+
