CLEANING AT THE END WORK
• Reduce pressure to the minimum (turn counterclockwise the
pressure control knob (H1) ).
• Press the ON/OFF switch (H2) placed on the box of the
electric motor, to stop the equipment.
• First release the residual pressure from the gun by holding
it pointed down towards the paint container, then open the
re-circulation valve (H3).
• Lift the suction pipe and replace the product tank with that
of the solvent (ensure it is compatible with the product being
used).
• Unscrew the gun nozzle (do not forget to clean it with sol-
vent!).
• Turn the ON-OFF switch (H2) on the ON position and rotate
the pressure setting knob (H1) slightly clockwise.
• Make sure the solvent recycles the washing fluid from the
return tube (H4).
• Close the re-circulation valve (H5) .
• Point the gun at the product tank and, keeping the trigger
pressed, release the remaining product till a clean solvent
comes out. Now, release the trigger.
• Lift again the suction pipe and remove the solvent tank.
• Now point the gun at the solvent tank and press the trigger
so as to recover the residual solvent.
• As the pump starts idling, press the ON/OFF switch to
stop the equipment.
• In case of long storage, we recommend you to suck and
to leave light mineral oil inside the pumping group and the
flexible hose.
Follow the washing procedure before using
again the equipment.
