Larius DALI - Description of the Equipment

3
DALì
English
32
14
15
13
4 10
17
C
POS.
1
2
3
4
5
6
7
8
9
POS.
10
11
12
13
14
15
16
17
DESCRIPTION OF THE EQUIPMENT
Carriage
Electric / combustion motor
High pressure manometer
Setting valve
Hydraulic oil filling cap
Hydraulic body
Colour body
Suction and recirculation tube
High pressure feed tube
Description
LARIUS AT 250 gun
Fast clean
Tools box
Recirculation valve
Recirculation pipe connection
Feed tube connection
Adjustable handle
Tank (for "vertical Dalì" version)
Description
4
5
6
7
8
9
10
11
12
16
2
3
1
