- 3 -
SPECIFICATIONS
Electrical specifications apply for an operating temperature range of 15
o
F to 120
o
F
(-10
o
C to 50
o
C), relative humidity up to 80%.
Input Voltage of M3K-120V Test Set 100-125V, 50-60Hz, 2A
Input Voltage of M3K-240V Test Set 220-245V, 50-60Hz, 2A
High Voltage Mode (PRV/PFV)
Peak Reverse and Forward Voltage 0 - 5800 V
PK
Peak Leakage Current @ 3 Mohm 1.83 mA
Short Circuit Current 10 mA
Test Duration max. 15 seconds
Gate Mode
Gate Voltage 0 - 20 V
DC
, 10 ohm source impedance
Anode Voltage 14 - 18 V, 10 ohm, 1/2 sine wave
Panel Meters
PRV/PFV Mode
Peak Anode Voltage 6400 V
PK
Peak Leakage Current 19.99 mA
Gate Mode
Gate Voltage 19.99V
DC
Gate Current 1999 mA
Oscilloscope Input
PRV/PFV Mode
X- axis (voltage) sensitivity 1.0 V/div=1000 V/div
Y-axis (current) sensitivity 1.0 V/div=10 mA/div
Gate Mode (Anode Voltage/Current Curve)
X- axis (voltage) sensitivity 2.0 V/div=10 V/div (Anode Voltage)
Y-axis (current) sensitivity 2.0 V/div=1 A/div (Anode Current)
Case Dimensions (L x W x D) 19" x 14" x 7" / 49cm x 36cm x 18cm
Weight 20 Lbs. / 9.072 kg
Test Standard JEDEC JC22, RS397
