STB-6000 USER MANUAL
9
Video and Audio Connection
Connection Method 1: Composite
Quality = Fair to Good
The composite cable (supplied) comprises of 1 x Video Cable (yellow) , 1 x Left Channel
Audio (White) cable and 1 x Right Channel Audio (Red) cable.
Best Used for: Older CRT Type televisions or other displays with only a standard AV input.
Connection Method 2: HDMI
Quality = Best
HDMI (High-Definition Multimedia Interface) is the preferred connection method as the
HDMI cable (not supplied) allows full HD Digital signal transmission to the TV.
Best Used For: Any TV that has an HDMI input.
Audio Connection
Audio can be connected to an external amplifier / receiver.
1. Connect the Stereo Left and Right channels (White & Red) to the back of the Set Top Box and the
corresponding inputs on the back the audio device.
2. Connect a SPDIF Coaxial Audio Cable (not supplied) to the rear of the Set Top Box
and the corresponding inputs on the back the audio device for full surround sound.
FIRST TIME INSTALLATION
Once the STB-6000 has been connected to the
power and to the TV and after all audio
connections have been made properly, switch on
TV.
Press Power button to switch the Set Top Box (STB)
unit on.
If you are using the unit for the first time or have
restored the unit to Factory Default, the
Installation Guide Menu will appear on your TV screen.
OSD Language
To set the OSD (On Screen Display) Language press the LEFT/RIGHT buttons on the remote until the
desired Language is displayed and then press the DOWN button.
To Next Page
