BeamControl-Master BCM
NEDERLANDS24
BeamControl-Master BCM
bedieningsveld
1. Integrale grepen
2. bedieningsveld
3. verticale libel Z
4. hendel batterijvak
5. schroefdraadaansluiting
6. rotatiekop
7. batterijvak
8. schroefdraadaansluiting
9. horizontale libel X
10. nivelleer-schroef B
11. horizontale libel Y
12. nivelleer-schroef C
13. laserloodstraal
14. nivelleer-schroef A
15. snelheid, hoekbereik
16. Aan/Uit
17. IR-ontvangstveld
18. LED´s
19. modus handmatige ontvangst
20. scanmodus
21. rotatiemodus
2
3
4
5
1
6
7
8
9
14
10
11
12
13
15
16
17
18
21
20
19
