LaserRange-Master Gi5
17
1x 2x 3x 4x
1x 2x 3x 4x
The back of the device can be used as a reference surface
for measuring angles.
!
The back of the device can be used as a reference surface
for measuring angles.
!
Angle function 3:
Angle 1. measurement 2. measurement
function 3
The measurement results are determined automatically by the 360°
inclination sensor.
The measurement results are determined automatically by the 360°
inclination sensor.
Results
Results
Angle function 2:
Angle 1. measurement 2. measurement
function 2
The back of the device can be used as a reference surface
for measuring angles.
!
The measurement results are determined automatically by the 360°
inclination sensor.
Angle function 1:
Angle function 1 Measurement
Results
EN
