LaserLiner MultiMeter - Additional information on use

MultiMeter
15
GB
1
Rotary switch to set the
measuring function
2
Red input socket (+)
3
Black COM socket (–)
4
Red 10 A input socket (+)
5
LCD
6
Test prods
7
Measuring contacts:
red "+", black "–"
A
Measured value display
(3 1/2 segments, 1,999 digits)
B
Low battery charge
C
Negative measured values
D
Warning: High voltage
1
5
4
3
2
black
6
red
7
AB C
D
Additional information on use
Observe the technical safety regulations for working on electrical
systems, especially: 1. Safely isolating from power supply,
2. Securing to prevent system being switched on again,
3. Checking zero potential, two-pole, 4. Earthing and short-
circuiting, 5. Securing and covering adjacent live components.
• If possible, do not work alone. Carry out measurements in
the vicinity of hazardous electrical installations only under
the guidance of a qualied electrician.
• The measuring tools and accessories are not toys. Keep out
of reach of children.
