Technical data
Function Range Accuracy
Max. input voltage 300 V AC / DC
DC voltage
200 mV
± (0.5% rdg + 5 digits)
2,000 mV
± (0.8% rdg + 5 digits)
20 V
200 V
300 V
± (1.0% rdg + 5 digits)
AC voltage
200 V
± (1.2% rdg + 10 digits)
300 V
DC current
2,000 μA
± (1.0% rdg + 5 digits)
20 mA
200 mA
± (1.2% rdg + 5 digits)
10 A
± (2.0% rdg + 5 digits)
Batteries
1.5 V round cells / AA, AAA, C, D
1.2 V round cells (NiMH) / AA, AAA, C, D
9.0 V flat cells / E-block
8.4 V flat cells (NiMH) / E-block
Diode test / resistance
Test voltage max. 3.2 V
Resistance
200 Ω
± (1.0% rdg + 5 digits)
2,000 Ω
± (0.8% rdg + 5 digits)
20 kΩ
200 kΩ
2,000 kΩ
± (1.2% rdg + 5 digits)
Input sensitivity
1 MΩ (V DC) / 500 kΩ (V AC)
Polarity
Sign for negative polarity
LCD
(3 1/2 segments, 1,999 digits)
Fuse
F 250 mA / 300 V, F 10 A / 300 V,
(Ø 5 x 20 mm)
Protection class II, double insulation
Overvoltage
CAT III - 300 V
Pollution degree 2
Degree of protection
IP 20
Max. rel. humidity < 75% rH non-condensing
Operating temperature
0°C…40°C
Storage temperature -10°C…50°C
Power supply
1 x 9 V battery (NEDA 1604, IEC 6F22)
Dimensions 77 x 139 x 28 mm
Weight (incl. battery)
204 g
Test standards
EN61010-1, EN61010-2-030,
EN61010-2-033, EN61326-1, EN61326-2-2
Subject to technical alterations 12.15
