ThermoXplorer Pro
41
19
20.0
S1= 19.3S1= 19.3LH=17.2
18.3
LH=17.2
GB
Activate / deactivate vertical line measurement
Vertical line measurement works just like horizontal line measurement
(see chapter 18 ff.) and is used in the same manner.
Measurement
Level/Span
Setup
File
Measurement
Type
Vertical
All added measurement points, lines and areas are removed by selecting „None“.
!
Up to three measuring surfaces can be set at one time. They can be assigned measure-
ment-specic parameters as well as the following properties: maximum temperature,
minimum temperature, average temperature.
Measurement
Level/Span
Setup
File
All added measurement points, lines and areas are removed by selecting „None“.
!
To position horizontal lines
Activate / deactivate area measurement
Measurement
Type
Add Area
